Thanks to this powerful combo which includes the Quicrun WP1080 G2 ESC and the 555 Quicrun Brushed motor with 13T, the next 1/10 scale crawler adventure will turn into a fantastic experience.
The Hobbywing Quicrun WP1080 is with its G2 version one of the first ESCs with a real "Car Mode". This means that the direction of the motor can be switched in real time. This is possible by using the idle channel on the transmitter and thus providing a unique driving experience unlike any seen before. The handbrake force can also be adjusted in real time, which would otherwise have to be changed via external programming as known from other ESCs. Compared to the previous model, the Quicrun WP1080 G2 controller offers different upgrades. For example the BEC not only can be set to 6V and 7.4V - even 8.4V at 6A are now possible. A whopping 15 adjustable parameters and over 90 values also ensure that the ESC can be completely adapted to Your own needs.
Crawlers are well equipped with the matching motor, which is made of high-quality materials and has an adjustable timing from -20° up to +20°.
Features:
- Specially designed for 1/10 Rock Crawlers
- BEC: 4A continuous and up to 6A peak, adjustable to 6V, 7.4V or 8.4V
- Waterproof according to the IP67 standard
- 15 parameter items for personal ESC settings
- Perfectly adjustable drag brake
- Separate programming port
- Small, light and yet robust
- XT60 connector installed
- Great efficiency with adjustable timing
- Zero-togging torque design
- Incl. PCB board to avoid interference
- Easily dismantled for maintenance work
Technical Specifications:
| ESC | |
| Type: | Brushed |
| Current (cont./peak): | 80A/400A |
| Cells: | 2-3S LiPo / 5-9 cells NiMH |
| BEC: | Switch Mode: 6V/7.4V @ 3A, 6A peak |
| Battery Plug: | XT60 |
| Dimensions: | 37.2x31.9x18.4mm |
| Weight: | 70.2g |
| Waterproof: | Yes |
| Application: | 1/10 Rock Crawler |
| Motor | |
| Type: | Brushed |
| Turns: | 13T |
| RPM @ 7.4V: | 14 000 |
| Input Voltage: | <=12.6V |
| Slots: | 5 |
| Length: | 58.5mm |
| Diameter: | 36mm |
| Shaft Diameter: | 3.175mm |
| Weight: | 193g |
| Application: | 1/10 Crawler, Short Course Truck, Monster Truck |
Delivery:
1x Quicrun WP1080 G2 ESC
1x Quicrun Brushed 555 13T Motor
1x Manual (English)
