| Tuotekoodi: | TAK2106 |
|---|---|
| Numero: | G3462106 |
| Varastopaikka: | 0.0 |
| Ajanjakso: | Ajanjakso 1930-1949 |
| Ajoneuvotyyppi: | Tela-ajoneuvo |
| Valtio: | Saksa |
| Tuotemerkki: | Takom Models |
Sd.Kfz. 173 Pz.Jg. Jagdpanther
The 220.00000000000003px Panzerjäger Panther Sd.Kfz. 173, or Jagdpanther, was a heavy tank destroyer based on the chassis of the Panzer V Panther and was armed with the same long-barreled 8.8 cm gun as the Tiger II or ‘King Tiger’, and a single 7.92 mm MG-34 machine gun in the front glacis plate for local defense. The Jagdpanther had a good power-to-weight ratio and a powerful main gun, which enabled it to destroy any Allied tank. Based on the existing Panther chassis, the vehicle did not suffer too many mechanical problems, and had an upgraded transmission and final drive to counter the Panther's main weakness. The Jagdpanther was powered by the 700hp Maybach HL230 P30 V-12 petrol engine and a 7 speed forward, 1-speed reverse transmission system with a maximum speed of 46 km/h (28.6 mph) and a range of about 200 kilometers (99 miles). It was manned by a crew of five: a driver, radio-operator, commander, gunner and a loader.
Two main variants can be distinguished, the earlier (1944 model) G1 with a small internally-bolted main gun mantlet and a modified Panther A engine deck, and the later (1945 model) G2 with a larger, externally-bolted mantlet and a modified Panther G engine deck, though late G1s also had a larger mantlet. Early Jagdpanthers had two vision openings for the driver, whereas late versions had only one. The main gun originally had a monobloc gun barrel, but later versions were equipped with the PaK 43/4 gun with a two-part barrel. Early G1s (to September 1944) were given a distinctive pattern of Zimmerit anti-magnetic mine coating.
A total of 415 Jagdpanthers were produced from January 1944 by three manufacturers; MIAG produced 270 from January 1944 until the end of the war; Maschinenfabrik Niedersachsen-Hannover (MNH) produced 112 from November 1944; Maschinenbau und Bahnbedarf (MBA) produced 37 vehicles from December 1944.
